Description:

For more than 30 years, the Exmark Lazer Z has been the choice of more landscape professionals than any other zero-turn mower. For pros that demand the absolute best durability, productivity, cut quality and innovation, the Lazer Z X-Series is the number one choice. With more configuration options than any other Exmark mower, the Lazer Z X-Series is the pinnacle of state-of-the-art commercial mowers. Choose from 52-, 60-, or 72-inch UltraCut Series 6, or massive 96-inch UltraCut Rear Discharge cutting decks. Our exclusive flow control baffles and Adapt tools-free deck rake adjustment deliver Exmark Signature cut quality and higher cutting speeds in any mowing conditions. Powered by a choice of state-of-the-art big block EFI V-Twin commercial engines from Kawasaki, Kohler and Vanguard, the Lazer Z X-Series powers through the largest jobs with ease. A long-travel full suspension operator seat features isolation bumpers to deliver a smoother ride for reduced operator fatigue.

Specifications:

• UPC: 193308241517
• Cutting Deck Width: 72"
• Drive Type: Hydro-Drive
• Starter: Electric
• Steering Control: Hydraulically dampened twin levers (adjustable fore/aft & height) with 3-position dampers
• Caster Forks: 0.50" thick caster yoke arms
• Front Caster Tires: 13 x 6.5-6, smooth tread, semi-pneumatic
• Drive Tires: 24 x 12-12, 4 ply Grassmaster TL
• Safety Package: OPC, drive interlock, safety interlock indicators
• Parking Brake: Lever-actuated disc brake
• Frame: Heavy-duty 1.5" x 3" welded tubular steel (unibody)
• Blade Spindles: Sealed, no-maintenance; 7.75" housing, 30mm shaft, splined driver
• Electrical System: 12V battery, 30-amp alternator
• Standard Features: Engine hour meter, USB port, LED lights, phone tray, cup holder
• Seat: Deluxe 3-tone suspension seat with vibration control and isolation system
• Engine Brand: Kawasaki®
• Engine Model: FX820V
• Engine Displacement: 822 cc
• Engine Series: V-Twin
• Engine Speed: 3,600 RPM
• Fuel System: EFI (Electronic Fuel Injection) with throttle body, ECU, and electronic governor
• Air Filter: Heavy-duty canister type
• Fuel Capacity: 12-gallon single tank
• Fuel Type: Gasoline EFI
• Transmission: Two Exmark-exclusive Parker unitized pump/motor systems with cooling, filters, and reservoirs
• Transmission Speed: Infinitely variable
• Max Forward Speed: 0–11.5 mph
• Max Reverse Speed: 0–7.0 mph
• PTO Engagement: MagStop Electromagnetic clutch (250 ft-lb) with spot brake
• Drive Wheel Release: Yes (can move unit without engine running)
• Fuel Indicator: Electronic sender
• Deck Lift: Foot-controlled with Adapt system
• Carb Compliant: Yes
• ROPS: 2-post foldable with seat belt and latch
• Deck Style: Full-floating UltraCut Series 6
• Deck Construction:
• 10-gauge top (formed & seam welded)
• 7-gauge side skirt
• 7-gauge spindle mounts
• Cutting Heights: 1.0" to 5.5" (¼" increments)
• Blade Tip Speed: ~18,500 fpm
• Blades: 3 blades, each 24.5" long
• Overall Dimensions:
• Width: 84.9"
• Height: 70.5"
• Length: 87.1"
• Curb Weight: 1,304 lbs
